Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
353
5
Appendices
<Confirmation command format>
Before loading all setting data for the Sensor in binary data format, the Sensor checks whether or not it can
receive binary data.
<Confirmation command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Execution command format>
Loads all setting data for the Sensor in binary data format.
<Execution command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
File size scheduled to be sent Number of bytes of all setting data for the Sensor scheduled to be sent (integer
type)
BKD data (binary) All setting data for the Sensor to be loaded (binary data)
PR LOADB CR EB DK
File size scheduled to be sent
Space
(0x20)
Delimiter
Delimiter
CR OK
CR ER
Delimiter
LOADB CR BDK
BKD data (binary)
Space
(0x20)
Delimiter
Delimiter
CR OK
CR ER
Delimiter
