Omron FQ2-S Series User Manual

Command Control
354
FQ2-S/CH User’s Manual
for Communications Settings
PRECLBLOADB (Check) / CLBLOADB (Execute)
Loading calibration data (binary data)
The Sensor loads calibration data in binary format as the specified calibration number.
To execute this command, two types of commands are used, a confirmation command and an execution
command.
For how to execute the command using the confirmation command and the execution command, refer to
Binary Data File Load and Save Commands: p. 183.
<Confirmation command format>
Before loading calibration data in binary data format, the Sensor checks whether or not it can receive binary
data.
<Confirmation command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Execution command format>
Loads calibration data in binary data format.
<Execution command response format>
When the Command Is Processed Normally
PR LOADB CR EC BL
File size scheduled to be sent
Space
(0x20)
Delimiter
Delimiter
CR OK
CR ER
Delimiter
CL DB CR BL AO
Calibration number
Calibration data
(binary)
Space
(0x20)
Space
(0x20)
Delimiter
Delimiter
CR OK
