Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
355
5
Appendices
When the Command Is Not Processed Normally
<Parameter Descriptions>
PRECGRLOADB (Check) / CGRLOADB (Execute)
Loading all calibration data (binary data)
The Sensor loads all calibration data in binary data format.
To execute this command, two types of commands are used, a confirmation command and an execution
command.
For how to execute the command using the confirmation command and the execution command, refer to
Binary Data File Load and Save Commands: p. 183.
<Confirmation command format>
Before loading all calibration data in binary data format, the Sensor checks whether or not it can receive binary
data.
<Confirmation command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
File size scheduled to be sent Number of bytes of calibration data scheduled to be sent (integer type)
Calibration data number Specifies the calibration number you want to load. (Integer type)
Specify 0 to 31.
Calibration data (binary) Calibration data to be loaded (binary data)
CR ER
Delimiter
PR LOADB CR EC RG
File size scheduled to be sent
Space
(0x20)
Delimiter
Delimiter
CR OK
CR ER
Delimiter
