Omron FQ2-S Series User Manual

Command Control
356
FQ2-S/CH User’s Manual
for Communications Settings
<Execution command format>
Loads all calibration data in binary data format.
<Execution command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
PREDICLOADB (Check) / DICLOADB (Execute)
Loading model dictionary data (binary data)
The Sensor loads model dictionary data in binary data format as the model dictionary with the specified
number.
To execute this command, two types of commands are used, a confirmation command and an execution
command.
For how to execute the command using the confirmation command and the execution command, refer to
Binary Data File Load and Save Commands: p. 183.
<Confirmation command format>
Before loading model dictionary data in binary data format, the Sensor checks whether or not it can receive
binary data.
File size scheduled to be sent Number of bytes of all calibration data scheduled to send (integer type)
All calibration data (binary) All calibration data to be loaded (binary data)
LOADB CR CGR
All calibration data (binary)
Space
(0x20)
Delimiter
Delimiter
CR OK
CR ER
Delimiter
PR LOADB CR ED CI
File size scheduled to be sent
Space
(0x20)
Delimiter
FQ2-S_CH_comm.book 356 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
