Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
365
5
Appendices
<Execution command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
PREALLIMAGESAVEB (Check) / ALLIMAGESAVEB (Execute)
Outputting all image (binary data)
This command outputs all images stored in the Sensor memory in binary format.
To execute this command, two types of commands are used, a confirmation command and an execution
command.
For how to execute the command using the confirmation command and the execution command, refer to
Binary Data File Load and Save Commands: p. 183.
<Confirmation command format>
Before all images saved to the Sensor’s memory are output in binary data format, a check is performed to
determine if the data can be received by the external device that will receive the data.
<Confirmation command response format>
When the Command Is Processed Normally
Image data number Specifies the image data number (integer type) you want to output.
Specify 0 to 19.
Image data size Number of bytes of image data to output (integer type)
Image data (binary) Image data to output (binary data)
Image data (binary)
Delimiter
CR OK
CR
Delimiter
CR ER
Delimiter
PR SAVEB CR EA L I MAGEL
Delimiter
All image data size
Delimiter
CR OK
CR
Delimiter
FQ2-S_CH_comm.book 365 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
