FQ2-S/CH User’s Manual
for Communications Settings
When the Command Is Not Processed Normally
<Execution command format>
Outputs all image data stored in the Sensor memory in binary format.
<Execution command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
PRECLBSAVEB (Check) / CLBSAVEB (Execute)
Outputting calibration data (binary data)
This command outputs data with the specified calibration number in binary data format.
To execute this command, two types of commands are used, a confirmation command and an execution
command.
For how to execute the command using the confirmation command and the execution command, refer to
Binary Data File Load and Save Commands: p. 183.
<Confirmation command format>
Before calibration data in binary data format is output, a check is performed to determine if the data can be
received by the external device that will receive the data.
All image data size Number of bytes of image data to output (integer type)
All image data (binary) Image data to output (binary data)
CR ER
Delimiter
SAV EB CR A L I MAGEL
Delimiter
All image data (binary)
Delimiter
CR OK
CR
Delimiter
CR ER
Delimiter
PR SAV EB CR EC BL
Calibration data number
Space
(0x20)
Delimiter
