Omron FQ2-S Series User Manual

Command Control
368
FQ2-S/CH User’s Manual
for Communications Settings
PRECGRSAVEB (Check) / CGRSAVEB (Execute)
Outputting all calibration data (binary data)
This command outputs all calibration data in binary data format.
To execute this command, two types of commands are used, a confirmation command and an execution
command.
For how to execute the command using the confirmation command and the execution command, refer to
Binary Data File Load and Save Commands: p. 183.
<Confirmation command format>
Before all calibration data in binary data format is output, a check is performed to determine if the data can be
received by the external device that will receive the data.
<Confirmation command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Execution command format>
This command outputs the all calibration data in binary data format.
<Execution command response format>
When the Command Is Processed Normally
PR SAV EB CR EC RG
Delimiter
All calibration data size
Delimiter
CR OK
CR
Delimiter
CR ER
Delimiter
SAV EB CR CRG
Delimiter
All calibration data (binary)
Delimiter
CR OK
CR
Delimiter
