When the Command Is Not Processed Normally
<Parameter Descriptions>
PREDICSAVEB (Check) / DICSAVEB (Execute)
Outputting model dictionary data (binary data)
This command outputs model dictionary data with the specified number in binary data format.
To execute this command, two types of commands are used, a confirmation command and an execution
command.
For how to execute the command using the confirmation command and the execution command, refer to
Binary Data File Load and Save Commands: p. 183.
<Confirmation command format>
Before model dictionary data is output in binary data format, a check is performed to determine if the data can
be received by the external device that will receive the data.
<Confirmation command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Execution command format>
This command outputs model dictionary data in binary data format.
All calibration data size Number of bytes of all calibration data to output (integer type)
All calibration data (binary) All calibration data to output (binary data)
CR ER
Delimiter
PR SAV EB CR ED CI
Model dictionary data number
Space
(0x20)
Delimiter
CR
Model dictionary data size
Delimiter
CR OK
Delimiter
CR ER
Delimiter
SAV EB CR DCI
Delimiter
