Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
427
5
Appendices
● Save All Calibration Data: 280F 0070B000
Saves all calibration data as a file to the SD card inserted in the Touch Finder.
The destination for all calibration data is the following fixed directory on the SD card.
\Sensor name\CGP
Format
Response Format
End Codes
Parameter Descriptions
• If the specified file name already exists, this existing file will be overwritten.
• Do not turn off power to the Vision Sensor until there is a response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
All calibration data file name
(4 to 64 bytes)
28 0F 0070B000 64 characters max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 0070B000
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
All calibration data file
name
Specifies the all calibration data file name to be saved.
The file name extension (.cgp) can be omitted.
Important
FQ2-S_CH_comm.book 427 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
