Omron IntelliSense IA1B User Manual

Correct Usage
How to Take a Measurement
1. Press the START/STOP button and remain still, the cuff will start to
inflate automatically.
As the cuff begins to inflate, the monitor automatically determines your ideal
inflation level. Since this monitor detects the pulse even during inflation, do
not move your arm and remain still until the entire measurement process has
been completed.
Note:
Do not inflate the cuff if it is not wrapped around your arm.
2. Inflation stops automatically and measurement starts.
As the cuff slowly deflates, decreasing numbers appear on the display and
the Heart Symbol (
) flashes at every heartbeat.
In rare circumstances, a higher inflation may be necessary. In these cases,
the monitor automatically reinflates the cuff up to 30 mmHg higher than
the initial inflation and restarts the measurement.
16
How to Take a Measurement
EN-02-25[IA1B]-3 8/19/04, 10:05 AM17

Omron IntelliSense IA1B Specifications

Measurement Specifications

pressure measurement range	0 to 299 mmHg
pulse measurement range	40-180/min
pressure accuracy	±3mmHg or 2% of reading
pulse accuracy	±5% of reading

Power

power source	4 “AA” batteries
battery life	Approx. 300 uses

Operating Environment

operating temperature	10°C to 40°C
operating humidity	30 to 90% RH
storage temperature	-20°C to 60°C

Weight and Dimensions

main unit weight	Approximately 355 g
main unit dimensions	Approx. 155 mm(l) x 84 mm(w) x 131 mm(h)
cuff size	Approximately 152 mm(w) Cuff tube 600 mm(l)
