The 3D Visualizer is displayed on the right side of the main window.
2 Select RobotControlSettings from the device list in the Multiview Explorer.
3 Select V+ Jog Control from the View
menu on the main window.
The V+ Jog Control pane appears on the right side of the main window.
3 Implementation Example of Static Pick-and-place Equipment
3-61
NJ-series Robot Integrated System Startup Guide (O049)
3-3 Programming and Simulation Procedures
3
3-3-7 Teaching Positions

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
