3-3
Programming and Simulation Proce-
dures
This section describes the procedure for creating project files, programing, and setting and checking
operation in simulation.
The simulation function allows you to check the equipment operation in advance without purchasing
actual equipment.
3-3-1
Creating a Project File
Create a project in the Sysmac Studio.
1 Start the Sysmac Studio and click New Project in the Start page.
The Project Properties dialog box is displayed.
2 In the Project Properties dialog box, enter the Project name, Author, and Comment, and
select the Category, Device, and V
ersion
as shown in the figure below.
3 Select the Open in Emulation Mode check box, and click the Create button.
3 Implementation Example of Static Pick-and-place Equipment
3-18
NJ-series Robot Integrated System Startup Guide (O049)
