121
A-4-2 NQ to AB Micrologix Series
/i
8 PIN MINI DIN CONNECTOR PINOUTS
(PLC)
DB9 MALE PINOUTS (NQ)
Signals Pin number Pin number Signals
11
SG 2 2 TXD
33RXD
RXD 4 4
55SG
66
TXD 7 7
88
9
shield wire to DB9 body shield wire to DB9 body
12
34 5
67 8
