6-6 Communications Settings
6-29
Set the Bar Code Reader’s communications method for serial port A or serial port B.
The setting items for the Bar Code Reader will be displayed on the right side of the screen. Set
the Communications speed, data bits, stop bits, parity, and input method.
After setting, press the Write Button to save the settings.
• Setting Communications Conditions for Bar Code Reader Mode
Setting item Function Settings
Communication speed Sets the Communications speed for
communications with the Bar Code
Reader.
4800, 9600, or 19200 (bps)
Data bits Sets the data bit length. 7 or 8 bits
Stop bits Sets the data stop bit length. 1 or 2 bits
Parity Sets the data parity bits. None, odd, or even
Input method Sets the confirmation method used after
inputting data in the input column.
Auto or manual confirmation
To Next Page
