3-8 Installing the Controller Link Interface Unit
3-43
3-8-3 Installation Method for Controller Link Interface Unit
This section explains the method for mounting a Controller Link Interface Unit to the PT.
The Controller Link Interface Unit can be mounted to NS12 and NS10 PTs only. It cannot be
mounted to an NS7 PT.
Note
· Do not touch the surface of the substrate or mounted devices with your bare hands. Also,
discharge static electricity from your body in advance.
· After mounting the Controller Link Interface Unit to the PT, all fittings must be tightened
with the provided screws. Tighten the screws to a torque of 0.6 N×m.
· Always turn OFF the power to PT before mounting or removing the Unit. Follow the proce-
dures and install the Unit correctly.
· When the Controller Link Interface Unit is installed, the depth of the PT will increase by
35 mm.
· To install the Controller Link Interface Unit, secure sufficient space inside the control panel
beforehand.
