6-8 Special S
creens
6-39
1.
Selec
t
Video Configuration
from the list under
Special Function
, and c
lick the
Start
button.
The Video Configuration Window will be displayed.
2.
Pr
ess the
Back
Button to return to the
Sp
ecial
Window
.
Reference
Press the
Write
Button to save the adjustments to the displayed im
age.
When starting the PT next time, the saved settings for the adjustments will be autom
ati-
cally reflected on the display.
