Appendix 2 Specifications
A-5
A-2-2 Characteristics
@ Display Specifications
Specifications
Item
NS12-TS0@ NS10-TV0@ NS7-SV0@
Display device
High-definition TFT color
LCD
High-definition TFT color
LCD
STN color LCD
Number of dots
800 dot horizontal
´ 600 dot
vertical
640 dot horizontal ´ 480 dot
vertical
640 dot horizontal ´ 480 dot
vertical
Display color
256 colors
Display area
Width 246.0 mm ´ height
184.5 mm (12.1 inches)
Width 211.2 mm ´ height
158.4 mm (10.4 inches)
Width 160.42 mm ´ height
121.06 mm (7.7 inches)
Display
panel
View angle
Left/right
±60°
Top 45°, bottom 55°
Left/right ±60°
Top 35°, bottom 65°
Left/right ±50°
Top 40°, bottom 30°
Life expectancy 50,000 hours min. (See note 1.)
40,000 hours min. (See note
1.)
Brightness
adjustment
There are 3 levels of adjustment by operating the touch panel. (See note 2.)
Backlight
(See note 4.)
Backlight error
detection
Error is detected automatically, and the RUN indicator flashes green as notification.
(See note 3.)
Front panel
indicators
RUN
Lit green: PT is operating normally.
Flashing green: The Memory Card transfer has ended normally or a backlight
error was detected immediately after power was turned ON.
Lit orange: Immediately after power turns ON, indicates file system check in
progress, battery low, or disconnected and operating normally.
Flashing orange: Memory Card transfer in progress.
Flashing red: Memory Card transfer has ended abnormally.
Note 1. This is the estimated time before brightness is reduced by half at room temperature and
humidity. It is not a guaranteed value.
The life expectancy will be drastically shortened if PT is used at low temperatures. For
example, using the PT at temperatures of 0
°C will reduce the life expectancy to approxi-
mately 10,000 hours (reference value).
2. The brightness cannot be adjusted much.
3. This function does not detect service life expectancy.
It detects when the backlight is not lit due to a disconnection or other errors. Backlight er-
ror detection indicates that all backlights (2) are OFF.
4. Contact your nearest OMRON representative to replace the backlight.
