Appendix 3 Dimensions
A-11
@ NS12/NS10 Cable Connection Dimensions
20
60
103
45
115.5
42
ETHERNET
PORT B
PORT A
@ NS7 (Includes Mounting Dimensions)
Mountin
g
p
anel
Mounting bracket
39 min.
42 max.
(Unit: mm)
