2-1 Connecting the Host
2-4
1:N Connectio
n (Connect
ing Multiple PTs t
o a Single Host)
Supported communications
methods
PT
commu-
nications
type
Host
commu-
nications
type
Supported connection methods
1:1 NT
Link
1:N NT
Links
FINS
Data
Links
Refer-
ence
page
RS-232C
RS-422A
Host
PTs
NS-AL00
2
Adapter
RS-422A cable
No
Yes
No
No
P.4-10
Ethernet
Ethernet
Host
PTs
Et
hern
et
HUB
10Base-T
twisted-pair straigh
t cable
No
No
Yes
No
P.5-2
Controller
Link (See
note.)
Controller
Link
Ho
st
PTs
Controll
er Lin
k
I
nte
rfac
e Unit
Specifie
d shielded
tw
isted-pa
ir cable
No
No
Yes
Yes
P. 5-15
Yes: Connection is possible.
No: Connection is not possible.
Note:
O
nly when a Controller Link Inter
face Unit (NS-CLK21) is mounted.
