3-6 Using Memory Cards
3-23
@ Automatic Upload
An automatic upload transfers system programs and screen data from the PT to the Memory
Card.
Set the DIP switch for automatic upload, as shown below.
The Memory Card cannot be used to transfer data when the DIP switch pins are set to com-
binations other than those specified here.
DIP switch pin and status
12345678
Operation
ON ON
OFF OFF OFF OFF OFF OFF
Automatically uploads system pro-
grams and screen data to bank 1.
ON ON
OFF OFF OFF OFF OFF OFF
Automatically uploads system pro-
grams and screen data to bank 2.
ON ON
OFF OFF OFF OFF OFF OFF
Automatically uploads system pro-
grams and screen data to bank 3.
ON ON
OFF OFF OFF OFF OFF OFF
Automatically uploads system pro-
grams and screen data to bank 4.
Use the following procedure to automatically upload data.
1.
Turn OFF the power to the PT.
2.
Set the DIP switch.
3.
Insert the Memory Card into the PT.
4.
Turn ON the power to the PT.
The system programs and screen data will be written to the Memory Card.
5.
The status of the PT indicator during data transfer is as shown below.
Do not remove the Memory Card during data transfer.
Transferring data: Indicator flashes orange.
Transferring completed: Indicator flashes green.
Error occurred: Indicator flashes red.
Refer to page 3-25 if an error occurs.
6.
Turn OFF the power.
7.
Remove the Memory Card.
8.
Turn OFF all the DIP switch pins.
9.
Turn ON the power.
For an automatic upload, 1 Mbyte of screen data is transferred in about 25 s.
A warning message will not be displayed when automatic upload is executed even if the PT
model, version, and language for the system programs and screen data that are stored in the
PT are different from those that are stored in the Memory Card
Always check carefully that the PT model and Memory Card details match before transferring
data automatically.
