3-6 Using Memory Cards
3-22
@ Automatic Download
An automatic download transfers system programs and screen data from the Memory Card to
the PT.
Set the DIP switch for automatic download, as shown below.
The Memory Card cannot be used to transfer data when the DIP switch pins are set to com-
binations other than those specified here.
DIP switch pin and status
12345678
Operation
ON
OFF OFF OFF OFF OFF OFF OFF
Automatically downloads bank 1 system
programs and screen data.
ON
OFF OFF OFF OFF OFF OFF OFF
Automatically downloads bank 2 system
programs and screen data.
ON
OFF OFF OFF OFF OFF OFF OFF
Automatically downloads bank 3 system
programs and screen data.
ON
OFF OFF OFF OFF OFF OFF OFF
Automatically downloads bank 4 system
programs and screen data.
Use the following procedure to automatically download data.
1.
Turn OFF the power to the PT.
2.
Set the DIP switch.
3.
Insert the Memory Card with the specified banks stored in it into the PT.
4.
Turn ON the power to the PT.
The system programs and screen data will be written to the PT.
5.
The status of the PT indicators during data transfer is as shown below.
Do not remove the Memory Card during data transfer.
Transferring data: Indicator flashes orange.
Transferring completed: Indicator flashes green.
Error occurred: Indicator flashes red.
Refer to page 3-25 if an error occurs.
6.
Turn OFF the power.
7.
Remove the Memory Card.
8.
Turn OFF all the DIP switch pins.
9.
Turn ON the power.
For an automatic download, 1 Mbyte of screen data is transferred in approximately 25 s.
A warning message will not be displayed when automatic download is executed even if the
PT model, version, and language for the system programs and screen data that are stored in
the PT are different from those that are stored in the Memory Card.
Always check carefully that the PT model and Memory Card details match before transferring
data automatically.
