4-2 1:N Host Connection
4-11
Host Units that Can be Connected between RS-232C Ports
PLC series
CPU Units with built-in
1:N NT Link function
CPU Units that can be connected with
Communications Boards or Units
CS Series
CS1G-CPU42/43/44/45-E(V1)
CS1H-CPU63/64/65/66/67-E(V1)
CS1G-CPU42H/43H/44H/45H
CS1H-CPU63H/64H/65H/66H/67H
CS1G-CPU42/43/44/45-E(V1) (See note 1.)
CS1H-CPU63/64/65/66/67-E(V1) (See note 1.)
CS1G-CPU42H/43H/44H/45H (See note 1.)
CS1H-CPU63H/64H/65H/66H/67H (See note 1.)
CJ Series
CJ1G-CPU44
CJ1G-CPU45
CJ1G-CPU44 (See note 2.)
CJ1G-CPU45 (See note 2.)
CJ1G-CPU42H/43H/44H/45H (See note 2.)
CJ1H-CPU65H/66H (See note 2.)
C200HE-CPU42(-Z)
C200HE-CPU32(-Z) (See note 3.)
C200HE-CPU42(-Z) (See note 3.)
C200HG-CPU43(-Z)
C200HG-CPU63(-Z)
C200HG-CPU33(-Z) (See note 3.)
C200HG-CPU43(-Z) (See note 3.)
C200HG-CPU53(-Z) (See note 3.)
C200HG-CPU63(-Z) (See note 3.)
C200HX-CPU44(-Z)
C200HX-CPU64(-Z)
C200HX-CPU65-Z
C200HX-CPU85-Z
C200HX-CPU34(-Z) (See note 3.)
C200HX-CPU44(-Z) (See note 3.)
C200HX-CPU54(-Z) (See note 3.)
C200HX-CPU64(-Z) (See note 3.)
C200HX-CPU65-Z (See note 3.)
C200HX-CPU85-Z (See note 3.)
C Series
CQM1H-CPU51 (See note 4.)
CQM1H-CPU61 (See note 4.)
Note 1. A CS1W-SCB21/41 Serial Communications Board or CS1W-SCU21 Serial Communications
Unit is required.
2. A CJ1W-SCU41 Serial Communications Unit is required.
3. A C200HW-COM02/COM04/COM05/COM06(-V1) Communications Board is required.
4. A CQM1H-SCB41 Serial Communications Board is required.
Reference RS-485 (two-wire) communications are not supported by the NS Series. Always use RS-
422A (four-wire).
