Specifications Appendix A
For an NT Link, 1:1, RS-422A Type
For an NT Link, 1:N, RS-232C Type
* To connect two or more PTs, NT-AL001 Adapters are required. When using an NT-AL001, the specifications
are as follows.
• RS-232C cable: 2 m max.
• RS-422A/485 cable: Total length 500 m max.
For an NT Link, 1:N, RS-422A/485 Type
For a High-speed NT Link, 1:N, RS-232C Type
* To connect two or more PTs, NT-AL001 Adapters are required. When using an NT-AL001, the specifications
are as follows.
• RS-232C cable: 2 m max.
• RS-422A/485 cable: Total length 500 m max.
Item Specification
Communications standard EIA RS-422A
Connector 25-pin D-SUB connector (female) (serial port B)
Number of Units connected 1:1
Transmission distance Max. 500 m
Item Specification
Communications standard EIA RS-232C
Connector 9-pin D-SUB connector (female) (serial port A)
25-pin D-SUB connector (female) (serial port B)
Number of Units connected 1:1 to 8
Transmission distance
Max. 15 m
*
Item Specification
Communications standard EIA RS-422A/485
Connector 25-pin D-SUB connector (female) (serial port B)
Number of Units connected 1:1 to 8
Transmission distance Max. 500 m
Item Specification
Communications standard EIA RS-232C
Connector 9-pin D-SUB connector (female) (serial port A)
25-pin D-SUB connector (female) (serial port B)
Number of Units connected 1:1 to 8
Transmission distance
Max. 15 m
*
