4 Safety Function Blocks
4 - 20
NX-series Safety Control Unit Instructions Reference Manual (Z931)
C041 49217 Reset Error 31 An undetected change to TRUE was detected for EDM1 and
Reset or equivalent signals were detected during EDM Error 21
status. (Both Reset and EDM1 changed to TRUE at the same
time.)
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
C051 49233 Reset Error 32 An undetected change to TRUE was detected for EDM2 and
Reset or equivalent signals were detected during EDM Error 22
status. (Both Reset and EDM2 changed to TRUE at the same
time.)
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
C061 49249 Reset Error 33 An undetected change to TRUE was detected for EDM1,
EDM2, and Reset or equivalent signals were detected during
EDM Error 23 status. (Reset, EDM1, and EDM2 changed to
TRUE at the same time.)
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
C071 49265 Reset Error 41 When EDM Error 31 status was entered, an undetected change
to TRUE in the Reset input was detected.
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
C081 49281 Reset Error 42 When EDM Error 32 status was entered, an undetected change
to TRUE in the Reset input was detected.
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
C091 49297 Reset Error 43 When EDM Error 33 status was entered, an undetected change
to TRUE in the Reset input was detected.
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
C010 49168 EDM Error 11 The EDM1 signal is not valid during the initial status of the actu-
ator. If S_OutControl is enabled when output is not possible,
the EDM1 sig
nal chan
ges to FALSE.
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
C020 49184 EDM Error 12 The EDM2 signal is not valid during the initial status of the actu-
ator. If S_OutControl is enabled when output is not possible,
the EDM2 signal changes to FALSE.
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
DiagCode (hexa-
decimal)
DiagCode
(decimal)
Status name Status description and output results
To Next Page
