Omron NX-SL series User Manual

4 - 21
4 Safety Function Blocks
NX-series Safety Control Unit Instructions Reference Manual (Z931)
4
SF_EDM
C030 49200 EDM Error 13 The EDM1 and EDM2 signals are not valid during the initial sta-
tus of the actuator. If S_OutControl is enabled when output is
not possible, the EDM1 and EDM2 signals change to FALSE.
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
C040 49216 EDM Error 21 The EDM1 signal is not valid during the initial status of the actu-
ator. The EDM1 signal changed to FALSE when output was not
possible, and the monitoring time ended.
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
C050 49232 EDM Error 22 The EDM2 signal is not valid during the initial status of the actu-
ator. The EDM2 signal changed to FALSE when output was not
possible, and the monitoring time ended.
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
C060 49248 EDM Error 23 The EDM1 and EDM2 signals are not valid during the initial sta-
tus of the actuator. The EDM1 and EDM2 signals changed to
FALSE when output was not possible, and the monitoring time
ended.
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
C070 49264 EDM Error 31 The EDM1 signal is not valid during the switched status of the
actuator. The EDM1 signal changed to TRUE when output was
possible, and the monitoring time ended.
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
C080 49280 EDM Error 32 The EDM2 signal is not valid during the switched status of the
actuator. The EDM2 signal changed to TRUE when output was
possible, and the monitoring time ended.
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
C090 49296 EDM Error 33 The EDM1 and EDM2 signals are not valid during the switched
status of the actuator. The EDM1 and EDM2 signals changed to
TRUE when output was possible, and the monitoring time
ended.
Re
ady = TRUE
S_EDM_Out = FALSE
Error = TRUE
C111 49425 Init Error R_TRIG was detected in the same cycle as S_OutControl and
Reset. (There may be a programming error.)
Ready = TRUE
S_EDM_Out = FALSE
Error = TRUE
DiagCode (hexa-
decimal)
DiagCode
(decimal)
Status name Status description and output results
