 FB-specific Status Codes (No Error)
DiagCode (hexa-
decimal)
DiagCode
(decimal)
Status name Status description and output results
0000 0 Idle The FB is disabled (default).
Ready = FALSE
S_EDM_Out = FALSE
Error = FALSE
8001 32769 Init The FB was activated and started. Automatic resetting was
FALSE at startup, so resetting is necessary.
Ready = TRUE
S_EDM_Out = FALSE
Error = FALSE
8010 32784 Output Disable EDM control is OFF. The timer starts when this state is
entered.
Ready = TRUE
S_EDM_Out = FALSE
Error = FALSE
8000 32768 Output Enable EDM control is ON. The timer starts when this state is
entered.
Ready = TRUE
S_EDM_Out = TRUE
Error = FALSE
