SF_MutingPar
8001 32769 Init The FB was started.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = FALSE
8002 32770 Safety Demand AOPD Muting is disabled. The control input from AOPD
is disabled.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = FALSE
8003 32771 Wait for Reset A safety request or error was detected and
cleared. The operator must respond with Reset.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = FALSE
8005 32773 Safe The safety function is operating.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = FALSE
8011 32785 Muting Forward Start 1 A forward muting sequence is being started
after MutingSwitch11 changed to TRUE. Moni-
toring is active for DiscTime11_12. Monitoring is
active for MaxMutingTime.
Ready = TRUE
S_AOPD_Out = TRUE
S_MutingActive = FALSE
Error = FALSE
8311 33553 Muting Forward Start 2 A forward muting sequence is being started
after MutingSwitch12 changed to TRUE. Moni-
toring is active for DiscTime11_12. Monitoring is
active for MaxMutingTime.
Ready = TRUE
S_AOPD_Out = TRUE
S_MutingActive = FALSE
Error = FALSE
DiagCode (hexadecimal)
DiagCode
(decimal)
Status name Status description and output results
