Omron NX-SL series

4 Safety Function Blocks
4 - 78
NX-series Safety Control Unit Instructions Reference Manual (Z931)
 FB-specific State Codes (No Error)
C005 49157 Parameter Error The value of DiscTime11_12, DiscTime21_22 or
MaxMutingTime is outside of the valid range.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
C006 49158 Error Timer MaxMuting Timing error: The muting operation time while
S_MutingActive = TRUE exceeded MaxMuting-
Time.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
C007 49159 Error Timer MS11_12 Timing error: Discrepancy time between
MutingSwitch11 and MutingSwitch12 exceeded
DiscTime11_12.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
C008 49160 Error Timer MS21_22 Timing error: Discrepancy time between
MutingSwitch21 and MutingSwitch22 exceeded
DiscTime21_22.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
*1. Find the DiagCode hexadecimal value with the information given in Status description and output results and then convert
it to the DiagCode decimal value.
DiagCode (hexadecimal)
DiagCode
(decimal)
Status name Status description and output results
0000 0 Idle The FB is disabled (default).
Ready = FALSE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = FALSE
8000 32768 AOPD Free Muting is disabled but the control input from
AOPD is active. If the muting timer is operating,
it stops.
Ready = TRUE
S_AOPD_Out = TRUE
S_MutingActive = FALSE
Error = FALSE
DiagCode (hexadecimal)
DiagCode
(decimal)
Status name Status description and output results
