NX-series Safety Control Unit Instructions Reference Manual (Z931)
C002 49154 Reset Error 2 When the Wait for Reset state was entered, an
undetected change to TRUE in the Reset input was
detected.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
C003 49155 Error Muting lamp An error was detected in the muting lamp.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
CYx4
---
*1
Error Muting sequence An error was detected during muting sequence state
8000, 8011, or 8311.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
Y = Sequence status
C0x4 = Error occurred in state 8000.
C1x4 = Error occurred in state 8011.
C2x4 = Error occurred in state 8311.
CFx4 = MutingEnable was not detected.
x = Muting sensor status when the error occurred (4
bits: LSB = MS_11; Next bit after LSB = MS_12).
CY04: Both switches are FALSE.
CY14: S_MutingSwitch11 = TRUE
CY24: S_MutingSwitch12 =TRUE
CY34: Both switches are TRUE.
C005 49157 Parameter Error The value of DiscTimeEntry or MaxMutingTime is
out of range.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
C006 49158 Error Timer MaxMuting Timing error: The muting operation time while
S_MutingActive = TRUE exceeded MaxMutingTime.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
C007 49159 Error Timer Entry Timing error: Discrepancy time in MutingSwitch11
and MutingSwitch12 changing to TRUE exceeded
DiscTimeEntry.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
DiagCode (hexadecimal)
DiagCode
(decimal)
Status name Status description and output results
