Omron NX-SL series

4 - 89
4 Safety Function Blocks
NX-series Safety Control Unit Instructions Reference Manual (Z931)
4
SF_MutingPar_2Sensor
 FB-specific State Codes (No Error)
*1. Find the DiagCode hexadecimal value with the information given in Status description and output results and then convert
it to the DiagCode decimal value.
DiagCode (hexadecimal)
DiagCode
(decimal)
Status name Status description and output results
0000 0 Idle The FB is disabled (default).
Ready = FALSE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = FALSE
8000 32768 AOPD Free Muting is disabled but the control input from
AOPD is active. If the muting timer is operating, it
stops.
Ready = TRUE
S_AOPD_Out = TRUE
S_MutingActive = FALSE
Error = FALSE
8001 32769 Init The FB was started.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = FALSE
8002 32770 Safety Demand AOPD Muting is disabled. The control input from AOPD
is disabled.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = FALSE
8003 32771 Wait for Reset A safety request or error was detected and
cleared. The operator must respond with Reset.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = FALSE
8005 32773 Safe The safety function is operating.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = FALSE
8011 32785 Muting Start 1 A muting sequence is being started after
MutingSwitch11 changed to TRUE. Monitoring is
active for DiscTimeEntry.
Ready = TRUE
S_AOPD_Out = TRUE
S_MutingActive = FALSE
Error = FALSE
