Omron NX-SL series

4 Safety Function Blocks
4 - 98
NX-series Safety Control Unit Instructions Reference Manual (Z931)
 FB-specific State Codes (No Error)
CYx4
---
*1
Error Muting sequence A muting sequence error was detected in state
8000, 8011, 8012, 8112, or 8122.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
Y = Sequence state (forward direction: 2 states,
backward direction: 2 states)
C0x4 = Error occurred in state 8000.
C1x4 = Error occurred in forward direction in state
8011.
C2x4 = Error occurred in forward direction in state
8012.
C3x4 = Error occurred in backward direction in
state 8122.
C4x4 = Error occurred in backward direction in
state 8112.
CFx4 = MutingEnable was not detected.
x = Sensor status when the error occurred (4 bits:
LSB = MS_11; MS_12; MS_21; MSB = MS_22).
C005 49157 Parameter Error The value of MaxMutingTime is outside of the
valid range.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
C006 49158 Error Timer MaxMuting Timing error: The effective muting time while
S_MutingActive = TRUE exceeded MaxMuting-
Time.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
*1. Find the DiagCode hexadecimal value with the information given in Status description and output results and then convert
it to the DiagCode decimal value.
DiagCode (hexadecimal)
DiagCode
(decimal)
Status name Status description and output results
0000 0 Idle The FB is disabled (default).
Ready = FALSE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = FALSE
DiagCode (hexadecimal)
DiagCode
(decimal)
Status name Status description and output results
