Omron NX-SL series User Manual

4 - 99
4 Safety Function Blocks
NX-series Safety Control Unit Instructions Reference Manual (Z931)
4
SF_MutingSeq
8000 32768 AOPD Free Muting is disabled. The control input from AOPD
is active.
Ready = TRUE
S_AOPD_Out = TRUE
S_MutingActive = FALSE
Error = FALSE
8001 32769 Init The FB was started.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = FALSE
8002 32770 Safety Demand AOPD Muting is disabled. The control input from AOPD
is disabled.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = FALSE
8003 32771 Wait for Reset A safety request or error was detected and
cleared. The operator must respond with Reset.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = FALSE
8005 32773 Safe The safety function is operating.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = TRUE
Error = FALSE
8011 32785 Muting Forward Start A forward muting sequence is being started and
there is no safety request.
Ready = TRUE
S_AOPD_Out = TRUE
S_MutingActive = FALSE
Error = FALSE
8012 32786 Muting Forward Active A forward muting sequence is in operation.
Ready = TRUE
S_AOPD_Out = TRUE
S_MutingActive = TRUE
Error = FALSE
8112 33042 Muting Backward
Active
A backward muting sequence is in operation.
Ready = TRUE
S_AOPD_Out = TRUE
S_MutingActive = TRUE
Error = FALSE
DiagCode (hexadecimal)
DiagCode
(decimal)
Status name Status description and output results
