Omron NX-SL series User Manual

4 Safety Function Blocks
4 - 106
NX-series Safety Control Unit Instructions Reference Manual (Z931)
 FB-specific State Codes (No Error)
DiagCode (hexadecimal)
DiagCode
(decimal)
Status name Status description and output results
0000 0 Idle The FB is disabled (default).
Ready = FALSE
S_OutControl = FALSE
Error = FALSE
8001 32769 Init Activate is set to TRUE and the FB is activated.
S_StartReset is ON. Resetting is required.
Ready = TRUE
S_OutControl = FALSE
Error = FALSE
8002 32770 Safe S_SafeControl changed to OFF, so S_OutControl
changed to OFF.
Ready = TRUE
S_OutControl = FALSE
Error = FALSE
8003 32771 Lock S_SafeControl changed to ON and S_AutoReset
changed to OFF, so the FB is waiting for a Reset
input.
Ready = TRUE
S_OutControl = FALSE
Error = FALSE
8010 32784 Output Disable ProcessControl is OFF.
Ready = TRUE
S_OutControl = FALSE
Error = FALSE
8000 32768 Output Enable ProcessControl is ON.
Ready = TRUE
S_OutControl = TRUE
Error = FALSE
