5.3 UL Standards
194 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Model Terminals
Recommended
Gauge
AWG, kcmil
Applicable Gauge
(IP20 Applicable
Gauge
*1
)
AWG, kcmil
Wire
Stripping
Length
*2
mm
Terminal Screw
Tightening Torque
N∙m (lb∙in.)
Size Shape
4023
R/L1, S/L2, T/L3 8
14 - 6
(14 - 6)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 10
14 - 6
(14 - 6)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
-, +1, +2 8
14 - 3
(14 - 3)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
B1, B2 12
14 - 10
(14 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
10
12 - 8
(-)
- M5 Phillips/slotted combo
2.0 - 2.5
(17.7 - 22.1)
4031
R/L1, S/L2, T/L3 6
14 - 3
(8 - 3)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
U/T1, V/T2, W/T3 8
14 - 4
(10 - 4)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
-, +1, +2 6
14 - 1
(8 - 1)
20 M6
Hex socket cap
(WAF: 5 mm)
5 - 5.5
(45 - 49)
B1, B2 10
14 - 8
(14 - 8)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
8
10 - 6
(-)
- M6 Phillips/slotted combo
5.4 - 6.0
(47.8 - 53.1)
4038
R/L1, S/L2, T/L3 6
14 - 3
(8 - 3)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
U/T1, V/T2, W/T3 8
14 - 4
(10 - 4)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
-, +1, +2 4
14 - 1
(8 - 1)
20 M6
Hex socket cap
(WAF: 5 mm)
5 - 5.5
(45 - 49)
B1, B2 10
14 - 8
(14 - 8)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
6
10 - 6
(-)
- M6 Phillips/slotted combo
5.4 - 6.0
(47.8 - 53.1)
4044
R/L1, S/L2, T/L3 4
14 - 4
(10 - 4)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
U/T1, V/T2, W/T3 6
14 - 6
(10 - 6)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
-, +1, +2 3
14 - 3
(10 - 3)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
B1, B2 8
14 - 8
(14 - 8)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
6
8 - 4
(-)
- M6 Phillips/slotted combo
5.4 - 6.0
(47.8 - 53.1)
4060
R/L1, S/L2, T/L3 4
14 - 4
(10 - 4)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
U/T1, V/T2, W/T3 4
14 - 4
(10 - 4)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
-, +1 3
14 - 3
(10 - 3)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
B1, B2 8
14 - 8
(14 - 8)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
6
8 - 4
(-)
- M6 Phillips/slotted combo
5.4 - 6.0
(47.8 - 53.1)
