4-184
4-4 Communication Function
4
Functions
127Dh
Acceleration pattern
selection
A097 R/W
0: Line
1: S-shape curve
2: U-shape curve
3: Inverted U-shape curve
4: EL-S-shape curve

127Eh
Deceleration pattern
selection
A098 R/W
0: Line
1: S-shape curve
2: U-shape curve
3: Inverted U-shape curve
4: EL-S-shape curve

127Fh Not used  
1280h Not used  
1281h
OI start frequency
A101
(HIGH)
R/W
0 to 40000 0.01 [Hz]
1282h
A101
(LOW)
R/W
1283h
OI end frequency
A102
(HIGH)
R/W
0 to 40000 0.01 [Hz]
1284h
A102
(LOW)
R/W
1285h OI start ratio A103 R/W O to OI end ratio 1 [%]
1286h OI end ratio A104 R/W OI start ratio to 100 1 [%]
1287h OI start selection A105 R/W
0: External start frequency
1: 0 Hz

1288h
to
128Ch
Not used  
128Dh
O2 start frequency
A111
(HIGH)
R/W
-40000 to 40000 0.01 [Hz]
128Eh
A111
(LOW)
R/W
128Fh
O2 end frequency
A112
(HIGH)
R/W
-40000 to 40000 0.01 [Hz]
1290h
A112
(LOW)
R/W
1291h O2 start ratio A113 R/W -100 to O2 end ratio 1 [%]
1292h O2 end ratio A114 R/W O2 start ratio to 100 1 [%]
1293h
to
12A4h
Not used  
12A5h
Acceleration curve
parameter
A131 R/W 1: Small curve to 10: Large curve 
12A6h
Deceleration curve
parameter
A132 R/W 1: Small curve to 10: Large curve 
12A7h
to
12AEh
Not used  
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
