4-185
4-4 Communication Function
4
Functions
12AFh
Operation frequency input
A setting
A141 R/W
0: Digital Operator (F001)
1: Digital Operator (FREQ adjuster)
2: Input O
3: Input OI
4: RS485 communication
5: Option 1
6: Option 2
7: Pulse train frequency
12B0h
Operation frequency input
B setting
A142 R/W
0: Digital Operator (F001)
1: Digital Operator (FREQ adjuster)
2: Input O
3: Input OI
4: RS485 communication
5: Option 1
6: Option 2
7: Pulse train frequency
12B1h Operator selection A143 R/W
0: Addition (A + B)
1: Subtraction (A - B)
2: Multiplication (A × B)
12B2h Not used 
12B3h
Frequency addition
amount
A145
(HIGH)
R/W
0 to 40000 0.01 [Hz]
12B4h
A145
(LOW)
R/W
12B5h
Frequency addition
direction
A146 R/W
0: Frequency reference + A145
1: Frequency reference - A145
12B6h
to
12B8h
Not used 
12B9h
EL-S-curve ratio 1 during
acceleration
A150 R/W 0 to 50 1 [%]
12BAh
EL-S-curve ratio 2 during
acceleration
A151 R/W 0 to 50 1 [%]
12BBh
EL-S-curve ratio 1 during
deceleration
A152 R/W 0 to 50 1 [%]
12BCh
EL-S-curve ratio 2 during
deceleration
A153 R/W 0 to 50 1 [%]
12BDh
to
1300h
Not used 
1301h Retry selection b001 R/W
0: Trip
1: 0-Hz start
2: Frequency matching start
3: Trip after frequency matching
deceleration stop
4: Active Frequency Matching restart
1302h
Allowable momentary
power interruption time
b002 R/W 3 to 250 0.1 [s]
1303h Retry wait time b003 R/W 3 to 1000 0.1 [s]
1304h
Momentary power
interruption/undervoltage
trip during stop selection
b004 R/W
0: Disabled
1: Enabled
2: Disabled during stop and deceleration
stop
Register
No.
Function name
Function
code
R/W Monitor and setting parameters
Resolution
