4-186
4-4 Communication Function
4
Functions
1305h
Momentary power
interruption retry time
selection
b005 R/W
0: 16 times
1: No limit
1306h
Input phase loss
protection selection
b006 R/W
0: Disabled
1: Enabled
1307h
Frequency matching lower
limit frequency setting
b007
(HIGH)
R/W
0 to 40000 0.01 [Hz]
1308h
b007
(LOW)
R/W
1309h Trip retry selection b008 R/W
0: Trip
1: 0-Hz start
2: Frequency matching start
3: Trip after frequency matching
deceleration stop
4: Active Frequency Matching restart
130Ah
Undervoltage retry time
selection
b009 R/W
0: 16 times
1: No limit
130Bh
Overvoltage/overcurrent
retry time selection
b010 R/W 1 to 3
130Ch Trip retry wait time b011 R/W 3 to 1000 0.1 [s]
130Dh Electronic thermal level b012 R/W 200 to 1000 0.1 [%]
130Eh
Electronic thermal
characteristics selection
b013 R/W
0: Reduction characteristics
1: Constant torque characteristics
2: Free setting
130Fh Not used
1310h
Free setting, electronic
thermal frequency 1
b015 R/W 0 to 400 1 [Hz]
1311h
Free setting, electronic
thermal current 1
b016 R/W 0 to Rated current 0.1 [A]
1312h
Free setting, electronic
thermal frequency 2
b017 R/W 0 to 400 1 [Hz]
1313h
Free setting, electronic
thermal current 2
b018 R/W 0 to Rated current 0.1 [A]
1314h
Free setting, electronic
thermal frequency 3
b019 R/W 0 to 400 1 [Hz]
1315h
Free setting, electronic
thermal current 3
b020 R/W 0 to Rated current 0.1 [A]
1316h Overload limit selection b021 R/W
0: Disabled
1: Enabled during acceleration/constant
speed
2: Enabled during constant speed
3: Enabled during acceleration/constant
speed (accelerated during
regeneration)
1317h Overload limit level b022 R/W
200 to 2000 ( 0.4 to 55 kW)
200 to 1800 (75 to 132 kW)
0.1 [%]
1318h Overload limit parameter b023 R/W 10 to 3000 0.01 [s]
Register
No.
Function name
Function
code
R/W Monitor and setting parameters
Resolution
