3-22
3-7 Parameter List
3
Operation
Analog input, Others
A005 O/OI selection
00: Switches between O/OI via terminal AT
01: Switches between O/O2 via terminal AT
02: Switches between O/FREQ adjuster via
terminal AT
(Enabled only when 3G3AX-OP01 is
used)
03: Switches between OI/FREQ adjuster via
terminal AT
(Enabled only when 3G3AX-OP01 is
used)
04: Switches between O2/FREQ adjuster via
terminal AT
(Enabled only when 3G3AX-OP01 is
used)
00 No  4-12
A006 O2 selection
00: O2 only
01: O/OI auxiliary frequency reference
(not reversible)
02: O/OI auxiliary frequency reference
(reversible)
03: O2 disabled
03 No 
4-12
A011 O start frequency
0.00 to 99.99
100.0 to 400.0
0.00 No Hz
4-14
A012 O end frequency
0.00 to 99.99
100.0 to 400.0
0.00 No Hz
A013 O start ratio 0. to O end ratio 0. No %
A014 O end ratio O start ratio to 100. 100. No %
A015 O start selection
00: External start frequency
(A011 set value)
01: 0 Hz
01 No 
A016 O, O2, OI sampling
1. to 30.
31. (with 500 ms filter ± 0.1 Hz hysteresis)
31. No  4-15
A017 Not used
Use "00".
* Do not change.
00 No 
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
