3-23
3-7 Parameter List
3
Operation
Multi-step speed, Jogging
A019
Multi-step speed
selection
00: Binary: 16-step selection with 4 terminals
01: Bit: 8-step selection with 7 terminals
00 No 4-16
A020
Multi-step speed
reference 0
0.0/Starting frequency to Max. frequency 6.00 Yes Hz
4-8
4-16
A220
* 2nd multi-step
speed reference 0
0.0/Starting frequency to 2nd Max. frequency 6.00 Yes Hz
A320
* 3rd multi-step speed
reference 0
0.0/Starting frequency to 3rd Max. frequency 6.00 Yes Hz
A021
Multi-step speed
reference 1
0.0/Starting frequency to Max. frequency
0.00
Yes Hz 4-16
A022
Multi-step speed
reference 2
0.00
A023
Multi-step speed
reference 3
0.00
A024
Multi-step speed
reference 4
0.00
A025
Multi-step speed
reference 5
0.00
A026
Multi-step speed
reference 6
0.00
A027
Multi-step speed
reference 7
0.00
A028
Multi-step speed
reference 8
0.00
A029
Multi-step speed
reference 9
0.00
A030
Multi-step speed
reference 10
0.00
A031
Multi-step speed
reference 11
0.00
A032
Multi-step speed
reference 12
0.00
A033
Multi-step speed
reference 13
0.00
A034
Multi-step speed
reference 14
0.00
A035
Multi-step speed
reference 15
0.00
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
