2-3 Name of each part
2 Preparation
S8BA-24D24D□□□LF
25
2
● S8BA-24D24D240LF
①
②
③
⑤
⑥
⑦
④
①Operation panel
②DC output terminal block
③DC input terminal block
④GR terminal（ ） 
⑤USB port
⑥RS232C port
⑦CONTACTport
● S8BA-24D24D360LF/S8BA-24D24D480LF
①
②
③
④
⑤
⑥
⑦
①Operation panel
②DC output terminal block
③DC input terminal block
④GR terminal（ ） 
⑤USB port
⑥RS232C port
⑦CONTACTport
