3 Installation and connection
3-2 Connection
S8BA-24D24D□□□LF
40
3-2 Connection
This section describes how to connect the UPS.
For cautions when connecting the UPS, refer to “Caution (for installation and connection)”
shown in the “Safety precautions” of the beginning of this manual.
3-2-1 Connecting a cable to the input terminal block and the
output terminal block
For details about the connectable sizes and recommended cable sizes, see the following
table.
Connectable sizes Cable
Solid wire
0.2〜4.0mm
2
Stranded wire
0.2〜2.5mm
2
AWG
AWG24〜12
Stripped cable length
8〜10mm
Recommended sizes
5A
Solid wire / Stranded wire
0.5mm
2
AWG
AWG20
10A
Solid wire / Stranded wire
0.75mm
2
AWG
AWG16
15A
Solid wire / Stranded wire
1.25mm
2
AWG
AWG14
20A
Solid wire / Stranded wire
2.0mm
2
AWG
AWG12
Temperature rating for recommended cable
90°C
