3-1 Installation

3 Installation and connection

S8BA-24D24D□□□LF

3. Close the “DIN rail mounting hooks” in the back of the UPS.

DIN rail mounting hooks

DIN rail

● Mounting on the floor

DIN rail

Default Chapter3
1 Overview of the Product21
- Features of this Product21
- Specifications22
2 Preparation24
3 Installation and Connection32
- Installation32
  - DIN Rail Installation36
  - Wall or Floor Mounting Procedure38
- Connection42
4 Check and Start Operation48
5 Maintenance and Inspection73
6 To Perform Shutdown Processing of the Devices When a Power Failure Occurs86
- The Outline on the UPS Monitoring Software86
  - What Is the Simple Shutdown Software86
  - How to Connect86
7 Using the I/O Signal Functions89
- I/O Signal Functions89
8 Troubleshooting92
9 References93
- Dimensions93
- Characteristic Data96
