3-2 Connection
3 Installation and connection
S8BA-24D24D□□□LF
43
3
■ Removing a connected cable from the terminal block
1. Insert the tip of a flat blade screwdriver with a 3 mm or less thin blade into a square hole
at the right of the terminal block and pull out the cable.
2. Pull out the flat blade screwdriver.
