4-2 Start and stop procedures and basic operation
4 Check and start operation
S8BA-24D24D□□□LF
53
4
● For shutdown by a BS signal
Durling power failure
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
High
Low
E
mpt
y
OFF
ON
ON
ON
ON
Battery restorage
Output from UPS
Display of “status
indicator” indicator
Beep
UPS operating mode
“Power” switch
(Re
mote ON/OFF)
Input power supply
BL signal (OUT)*
BS signal (IN)*
BU signal (OUT)*
Normal operation
Backup operation
0.2 sec
4 sec
*For details, see 7-1 I/O signal functions.
You can set a time from when a BS signal is detected
until the UPS is stopped in the range from 0 minute
(factory default setting) to 10 minutes.
See the BS signal delay time setting: 4-4-2 Settings
