Omron S8BA-24D24D120LF User Manual

6-1 The outline on the UPS monitoring software
6 To perform shutdown processing of the devices when a power failure occurs
S8BA-24D24D□□□LF
85
6
● RS232C connection
Connect to
RS232C
port on UPS
Connector
2. Install “Simple Shutdown Software” in your computer.
* For details, see the manual for the above software.
Connect to
the RS232C
port.
Connector
Connect to the RS232C
port of your computer
● Cable pin configuration
【
UPS side
】
【
PC side
】
I/O
O
-
I
RJ45
Name
TXD
GND
RXD
F
1
2
3
4
5
6
7
8
M
1
2
3
4
5
6
7
8
S8BW-C01
Connection
F
1
2
3
4
5
6
7
8
9
M
1
2
3
4
5
6
7
8
9
Dsub-9pin
Name
DCD
RxD
TxD
DTR
SG
DSR
RTS
CTS
RI
I/O
I
I
O
O
-
I
O
I
I
