9-1 Dimensions
9 References
S8BA-24D24D□□□LF
93
9
■Optional items for rail mounting
●Support rail (Alminum)
PFP-100N
PFP-50N
4.5
15 25 25
10 10
1,000（500）＊
25 25 15（5）＊
35
±0.3
7.3
±0.15
27
±0.15
1
*PFP-50Ndimensionsare
giveninparentheses.
●Support rail (Alminum)
PFP-100N2
4.5
15 25 25
10 10
1,000
25 25 15
1 1.5
29.2242735
±0.3
16
●Fastening plate (End plate)
PFP-M
50
11.5
10
M4×8
Panheadscrew
M4springwasher 4.8
1.3
1.8
1
10
6.2
1.8
35.5 35.3
Note 1: If the DIN rail is subjected to vibration or shocks, scrap metal can be produced
because of aluminum abrasion. In such a case, use a steel DIN rail instead.
Note 2：If the product slides sideways, attach an end plate (PFP-M) on both sides of the
main body.
