Standard Models and Specifications
■ Peripheral Cable Connectors
■ Parameter Units
■ External Regeneration Resistors
■ DC Reactors
■ Front-panel Brackets
Specifications Model
Analog Monitor Cable (CN4) 1 m R88A-CMW001S
Computer Monitor Cable (CN3) DOS 2 m R7A-CCA002P2
PC98 2 m R7A-CCA002P3
Control I/O Connector (CN1) R88A-CNU01C
Encoder Connector (CN2) R7A-CNA01R
Encoder Connector (Servomotor end) R7A-CNA02R
Communications Cable 1 m XW2Z-100J-C1
2 m XW2Z-200J-C1
Specifications Model
Hand-held (with 1-m cable) R7A-PR02A
Specifications Model
Resistor 220 W 47
Ω R88A-RR22047S
Specifications Model
For R7D-APA3L/APA5L/APA01L R88A-PX5063
For R7D-AP02L R88A-PX5062
For R7D-AP04L R88A-PX5061
For R7D-APA3H/APA5H/AP01H R88A-PX5071
For R7D-AP02H R88A-PX5070
For R7D-AP04H R88A-PX5069
For R7D-AP08H R88A-PX5061
Specifications Model
For the SMARTSTEP A Series R88A-TK01W
