Omron SYSMAC CS1W-SCB41-V1 User Manual

120
RS-232C and RS-422A/485 Wiring Section 3-4
4. Return the heat-shrinking tube to the soldered portion, then heat the tube
to shrink it in place.
3-4-5 Assembling Connector Hood
Assemble the connector hood as shown below.
Soldering iron
Heat-shrinking tube
Inside diameter:
1.5 mm, l = 10
1 mm
Heat-shrinking tube
End connected to FG
Aluminum foil tape
Grounding plate
End not connected to FG
Adhesive tape
