C-mode (Host Link) Command Master Appendix C
ABORT (XZ Command)
(Sequence No. 720 (Hex 02D0))
Initializes the port of the specified Host Link Unit.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None. (Specify a dummy value for the operand, such as #0000.)
INITIALIZE (** Command)
(Sequence No. 721 (Hex 02D1))
Initialize the ports of all Host Link Units.
Send Data Word Allocation (3rd Operand of PMCR(260))
None. (Specify a dummy value for the operand, such as #0000.)
Receive Data Word Allocation (4th Operand of PMCR(260))
None. (Specify a dummy value for the operand, such as #0000.)
Offset Contents (data format) Data
+0
Number of send data words Always 0002 hex (2 decimal)
+1
(Undefined) Host Link unit
No.
(2 digits BCD)
00 to 31
+0
+1
Number of send data words
(Undefined)
First word of
send data
Host Link unit No.
(2 digits BCD)
