Omron SYSMAC CS1W-SCB41-V1 User Manual

421
Host Link FINS Command Master Appendix D
The values in parentheses are hexadecimal
The relationship between the Host Link FINS command code/response frame and the PMCR(260) instruction
operand is shown in the following diagram.
756 (02F4) MEMORY AREA
WRITE
Sends command code 0102 hex to the specified Host
Link Unit and writes data to consecutive I/O memory area
words.
Ye s Ye s
757 (02F5) CIO AREA WRITE Sends command code 0102 hex to the specified Host
Link Unit and writes data to consecutive CIO Area words.
Ye s Ye s
758 (02F6) DM AREA WRITE Sends command code 0102 hex to the specified Host
Link Unit and writes data to consecutive DM Area words.
Ye s Ye s
759 (02F7) EM0 AREA WRITE Sends command code 0102 hex to the specified Host
Link Unit and writes data to consecutive EM Area words
in Bank 0.
Ye s Ye s
760 (02F8) MEMORY AREA
FILL
Sends command code 0103 hex to the specified Host
Link Unit and writes the same data to consecutive I/O
memory area words.
Ye s Ye s
761 (02F9) CIO AREA FILL Sends command code 0103 hex to the specified Host
Link Unit and writes the same data to consecutive CIO
Area words.
Ye s Ye s
762 (02FA) DM AREA FILL Sends command code 0103 hex to the specified Host
Link Unit and writes the same data to consecutive DM
Area words.
Ye s Ye s
763 (02FB) EM0 AREA FILL Sends command code 0103 hex to the specified Host
Link Unit and writes the same data to consecutive EM
Area words in Bank 0.
Ye s Ye s
764 (02FC) OPERATING MODE
CHANGE (RUN)
Sends command code 0401 hex to the specified Host
Link Unit and changes the CPU Unit’s operating mode to
MONITOR mode.
Ye s Ye s
765 (02FD) OPERATING MODE
CHANGE (STOP)
Sends command code 0401 hex to the specified Host
Link Unit and changes the CPU Unit’s operating mode to
PROGRAM mode.
Ye s Ye s
766 (02FE) UNIT DATA READ Sends command code 0501 hex to the specified Host
Link Unit and stores the Unit data starting from the desig-
nated word.
Ye s Ye s
767 (02FF) UNIT STATUS
READ
Sends command code 0601 hex to the specified Host
Link Unit and stores the Unit’s operating conditions (sta-
tus) starting from the designated word.
Ye s Ye s
Sequence
No.
Communications
sequence name
Function Ladder interface
Send word
allocation
Receive
word
allocation
